[STAINLESS STANDARD] Cam Follower CF..MAB

Hexagon socket on both sides (Ød: 10mm ~ 30mm)

Manufacturer	JNS
Description	[Stainless Standard] Cam Follower: hexagon socket on both sides
Part Number	JNS_CF12MAB
Installation Method	Hexagon socket on both sides
Material	STAINLESS STEEL
Outer Diameter D (mm)	30

Outer Ring	Cylinderical
Outer Ring Width C (mm)	14
Roller Guide	Cage
Seal Structure	Shield Type
Stud Diameter d (mm)	12
Type	Standard

Modelli CAD

Richiedi un preventivo

Prodotto da selezionare

Index	Selector	Part Number	Description	Installation Method	Material	Outer Diameter D (mm)	Outer Ring	Outer Ring Width C (mm)	Roller Guide	Overall Length B1 (mm)	Seal Structure	Stud Diameter d (mm)	Thread Stud G	Type
1	1	JNS_CF12MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Cage	40	Shield Type	12	M12 x 1.5	Standard
2	12	JNS_CF12UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Cage	40	Sealed Type	12	M12 x 1.5	Standard
3	23	JNS_CF12RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Cage	40	Shield Type	12	M12 x 1.5	Standard
4	34	JNS_CF12UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Cage	40	Sealed Type	12	M12 x 1.5	Standard
5	45	JNS_CF12VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Full Complement	40	Shield Type	12	M12 x 1.5	Standard
6	56	JNS_CF12VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Standard
7	67	JNS_CF12VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Full Complement	40	Shield Type	12	M12 x 1.5	Standard
8	78	JNS_CF12VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Standard
9	88	JNS_CF12-1MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Cage	40	Shield Type	12	M12 x 1.5	Standard
10	2	JNS_CF12-1UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Cage	40	Sealed Type	12	M12 x 1.5	Standard
11	3	JNS_CF12-1RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Cage	40	Shield Type	12	M12 x 1.5	Standard
12	4	JNS_CF12-1UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Cage	40	Sealed Type	12	M12 x 1.5	Standard
13	5	JNS_CF12-1VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Full Complement	40	Shield Type	12	M12 x 1.5	Standard
14	6	JNS_CF12-1VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Standard
15	7	JNS_CF12-1VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Full Complement	40	Shield Type	12	M12 x 1.5	Standard
16	8	JNS_CF12-1VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Standard
17	9	JNS_CF16MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Cage	52	Shield Type	16	M16 x 1.5	Standard
18	10	JNS_CF16UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Cage	52	Sealed Type	16	M16 x 1.5	Standard
19	11	JNS_CF16RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Cage	52	Shield Type	16	M16 x 1.5	Standard
20	13	JNS_CF16UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Cage	52	Sealed Type	16	M16 x 1.5	Standard
21	14	JNS_CF16VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Full Complement	52	Shield Type	16	M16 x 1.5	Standard
22	15	JNS_CF16VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Full Complement	52	Sealed Type	16	M16 x 1.5	Standard
23	16	JNS_CF16VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Full Complement	52	Shield Type	16	M16 x 1.5	Standard
24	17	JNS_CF16VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Full Complement	52	Sealed Type	16	M16 x 1.5	Standard
25	18	JNS_CF18MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Cage	58	Shield Type	18	M18 x 1.5	Standard
26	19	JNS_CF18UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Cage	58	Sealed Type	18	M18 x 1.5	Standard
27	20	JNS_CF18RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Cage	58	Shield Type	18	M18 x 1.5	Standard
28	21	JNS_CF18UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Cage	58	Sealed Type	18	M18 x 1.5	Standard
29	22	JNS_CF18VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Full Complement	58	Shield Type	18	M18 x 1.5	Standard
30	24	JNS_CF18VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Full Complement	58	Sealed Type	18	M18 x 1.5	Standard
31	25	JNS_CF18VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Full Complement	58	Shield Type	18	M18 x 1.5	Standard
32	26	JNS_CF18VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Full Complement	58	Sealed Type	18	M18 x 1.5	Standard
33	27	JNS_CF20MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Cage	66	Shield Type	20	M20 x 1.5	Standard
34	28	JNS_CF20UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Cage	66	Sealed Type	20	M20 x 1.5	Standard
35	29	JNS_CF20RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Cage	66	Shield Type	20	M20 x 1.5	Standard
36	30	JNS_CF20UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Cage	66	Sealed Type	20	M20 x 1.5	Standard
37	31	JNS_CF20VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Full Complement	66	Shield Type	20	M20 x 1.5	Standard
38	32	JNS_CF20VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Standard
39	33	JNS_CF20VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Full Complement	66	Shield Type	20	M20 x 1.5	Standard
40	35	JNS_CF20VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Standard
41	36	JNS_CF20-1MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Cage	66	Shield Type	20	M20 x 1.5	Standard
42	37	JNS_CF20-1UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Cage	66	Sealed Type	20	M20 x 1.5	Standard
43	38	JNS_CF20-1RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Cage	66	Shield Type	20	M20 x 1.5	Standard
44	39	JNS_CF20-1UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Cage	66	Sealed Type	20	M20 x 1.5	Standard
45	40	JNS_CF20-1VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Full Complement	66	Shield Type	20	M20 x 1.5	Standard
46	41	JNS_CF20-1VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Standard
47	42	JNS_CF20-1VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Full Complement	66	Shield Type	20	M20 x 1.5	Standard
48	43	JNS_CF20-1VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Standard
49	44	JNS_CF24MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Cage	80	Shield Type	24	M24 x 1.5	Standard
50	46	JNS_CF24UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Cage	80	Sealed Type	24	M24 x 1.5	Standard
51	47	JNS_CF24RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Cage	80	Shield Type	24	M24 x 1.5	Standard
52	48	JNS_CF24UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Cage	80	Sealed Type	24	M24 x 1.5	Standard
53	49	JNS_CF24VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Full Complement	80	Shield Type	24	M24 x 1.5	Standard
54	50	JNS_CF24VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Standard
55	51	JNS_CF24VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Full Complement	80	Shield Type	24	M24 x 1.5	Standard
56	52	JNS_CF24VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Standard
57	53	JNS_CF24-1MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Cage	80	Shield Type	24	M24 x 1.5	Standard
58	54	JNS_CF24-1UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Cage	80	Sealed Type	24	M24 x 1.5	Standard
59	55	JNS_CF24-1RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Cage	80	Shield Type	24	M24 x 1.5	Standard
60	57	JNS_CF24-1UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Cage	80	Sealed Type	24	M24 x 1.5	Standard
61	58	JNS_CF24-1VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Full Complement	80	Shield Type	24	M24 x 1.5	Standard
62	59	JNS_CF24-1VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Standard
63	60	JNS_CF24-1VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Full Complement	80	Shield Type	24	M24 x 1.5	Standard
64	61	JNS_CF24-1VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Standard
65	62	JNS_CF30MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
66	63	JNS_CF30UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
67	64	JNS_CF30RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
68	65	JNS_CF30UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
69	66	JNS_CF30VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
70	68	JNS_CF30VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard
71	69	JNS_CF30VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
72	70	JNS_CF30VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard
73	71	JNS_CF30-1MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
74	72	JNS_CF30-1UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
75	73	JNS_CF30-1RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
76	74	JNS_CF30-1UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
77	75	JNS_CF30-1VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
78	76	JNS_CF30-1VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard
79	77	JNS_CF30-1VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
80	79	JNS_CF30-1VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard
81	80	JNS_CF30-2MAB	[Stainless Standard] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
82	81	JNS_CF30-2UUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
83	82	JNS_CF30-2RMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Standard
84	83	JNS_CF30-2UURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Standard
85	84	JNS_CF30-2VMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
86	85	JNS_CF30-2VUUMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard
87	86	JNS_CF30-2VRMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Standard
88	87	JNS_CF30-2VUURMAB	[Stainless Standard] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Standard

Descrizione prodotto

UU: with seals - R: crowned outer ring - V: full complement
