1MT171 Piston Actuator

The 1MT171 Piston Actuator is a highly reliable electroexplosive device used in ordnance defense systems.

Manufacturer	EAGLEPICHER
Description	1MT171 Piston Actuator
Part number	1MT171-2
Weight	2.25 gm Max
Lead	0.018” (.46 mm) diameter
Piston extension	0.245” (6.22 mm) approx.

Modelli CAD

Richiedi un preventivo

Prodotto da selezionare

Index	Selector	Part Number	Bridge Resistance @70°F (21°C) (Ω)	All-Fire Current @ -65°F (-54°C) 10 ms (Amp, Min.)	No-Fire Current @ 160°F (71°C) 1 min (Amp, Min.)	Insulation Resistance @ 500 Vdc (MEG, Min.)
1	1	1MT171-2	0.16 ± 0.10	4.0	1.00	10
2	2	1MT171-4	2.25 ± 0.75	0.9 ± 0.1	0.10	10

Descrizione prodotto

It is used as an electrically activated system to penetrate bursts discs. The 1MT171 Piston Actuator is a completely self-contained, non-sealed electroexplosive device. The hardness of the pointed piston is 220 Bn. The leads are copper cored and gold plated.

Variations
Two models (1MT171-2 and 1MT171-4) are described here. Modifications in bridge resistance can be made to meet specific requirements.

Characteristics
Some of the characteristics listed here are nominal; others are levels to which the units have been tested. There are no limits on design capabilities. Please consult an EaglePicher representative before using this data as a specification.

Documentazione

1MT171 Piston Actuator
