Tact SwitchesTC-1109DE-C-G


Manufacturer Guangdong XKB Technology Co., Ltd.
Description Tact SwitchesTC-1109DE-C-G
Part Number TC-1109DE-C-G
Installation mode DPI type
Operation mode SIDE OPERATION
Stroke types 0.25±0.05mm
Support frame without
Overall dimension W4.5xD4.5xH
Operating feeling Sensibility
Height from mounting surface (mm) 6.5
