MAGNUS MRFID C B CA M - RFID Safety Switch, Combo (Sensor + Actuator), Actuator Coding, Automatic Restart, M12 connector, Interaxis 78 mm

Manufacturer ReeR Safety
Description RFID Safety Switch, Combo (Sensor + Actuator), Actuator Coding, Automatic Restart, M12 connector, Interaxis 78 mm
Manufacturer Part Number 1292100
Safety level (SIL / PL) SIL 3 - SILCL 3 - PL e - Cat. 4
Safety outputs 2 OSSD (400 mA)
Approvals CE, TÜV, UL, High Vibrations
Response Time (ms) 75
Digital Inputs 2 Digital Inputs
Sensor Type RFID Switch
Fastening M4 screws with flat head (e.g. M4 cheese head screws ISO 4762)
Degree of protection IP67 - IP69K (connector excluded)
CAD models
Request for quotation
Please make sure this software has been installed.

Product selection

Manufacturer Part NumberSafety level (SIL / PL)Power supply (VDC)Safety outputsApprovalsDimensions HxWxD (mm)Response Time (ms)Test OutputsDigital InputsSensor TypeSizeConnectionFasteningDegree of protectionOperating temperature (°C)Status Signaling
1292100SIL 3 - SILCL 3 - PL e - Cat. 424 ± 20%2 OSSD (400 mA)CE, TÜV, UL, High Vibrations26 x 88 x 137512 Digital InputsRFID Switch78 mm InteraxisConnectorM4 screws with flat head (e.g. M4 cheese head screws ISO 4762)IP67 - IP69K (connector excluded)-25 ... 70Three colours LED for diagnostic and status

Product Description

Actuator Coding: the actuator is free and not specifically assigned to the sensor (one actuator can work with multiple sensors)
