Central drive conveyor with timing belt


Manufacturer ELCOM
Description Central drive conveyor with timing belt, width of 40mm, length of 400mm, Motorization 230V single phase 50Hz, power 0,09 kw with a speed of 2m/min to right, in position A1, belt in T5 PAR+PAZ
Reference C-040-11-400-T5 PAR+PAZ-m1-a1-r
Omniclass number 23.21.33.11
A width 40 mm
L conveyor length 400 mm
Carried load 0 kg
Extremity pulley ø 21 -
L1 length 70 mm
Belt type T5 PAR+PAZ
Foot type -
H height -
L2 length -
Motorization Motorization 230V single phase 50Hz, power 0,09 kw
Speed 2 m/min
Conveyor side right
Motor position A1
Lateral guide type -
Plates no
Width between lateral guides -
Lateral guide length -
