[STAINLESS ECCENTRIC] Cam Follower CFH..MAB

Hexagon socket on both sides (Ød: 12mm ~ 30mm)

Manufacturer	JNS
Description	[Stainless Eccentric] Cam Follower: hexagon socket on both sides
Part Number	JNS_CFH12MAB
Installation Method	Hexagon socket on both sides
Material	STAINLESS STEEL
Outer Diameter D (mm)	30

Outer Ring	Cylinderical
Outer Ring Width C (mm)	14
Roller Guide	Cage
Seal Structure	Shield Type
Stud Diameter d (mm)	12
Type	Eccentric

modelmi CAD

Žiadosť o cenovú ponuku

Výber produktov

Index	Selector	Part Number	Description	Installation Method	Material	Outer Diameter D (mm)	Outer Ring	Outer Ring Width C (mm)	Roller Guide	Overall Length B1 (mm)	Seal Structure	Stud Diameter d (mm)	Thread Stud G	Type
1	1	JNS_CFH12MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Cage	40	Shield Type	12	M12 x 1.5	Eccentric
2	12	JNS_CFH12UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Cage	40	Sealed Type	12	M12 x 1.5	Eccentric
3	23	JNS_CFH12RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Cage	40	Shield Type	12	M12 x 1.5	Eccentric
4	34	JNS_CFH12UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Cage	40	Sealed Type	12	M12 x 1.5	Eccentric
5	45	JNS_CFH12VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Full Complement	40	Shield Type	12	M12 x 1.5	Eccentric
6	56	JNS_CFH12VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	30	Cylinderical	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Eccentric
7	67	JNS_CFH12VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Full Complement	40	Shield Type	12	M12 x 1.5	Eccentric
8	78	JNS_CFH12VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	30	Crowned	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Eccentric
9	88	JNS_CFH12-1MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Cage	40	Shield Type	12	M12 x 1.5	Eccentric
10	2	JNS_CFH12-1UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Cage	40	Sealed Type	12	M12 x 1.5	Eccentric
11	3	JNS_CFH12-1RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Cage	40	Shield Type	12	M12 x 1.5	Eccentric
12	4	JNS_CFH12-1UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Cage	40	Sealed Type	12	M12 x 1.5	Eccentric
13	5	JNS_CFH12-1VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Full Complement	40	Shield Type	12	M12 x 1.5	Eccentric
14	6	JNS_CFH12-1VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	32	Cylinderical	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Eccentric
15	7	JNS_CFH12-1VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Full Complement	40	Shield Type	12	M12 x 1.5	Eccentric
16	8	JNS_CFH12-1VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	32	Crowned	14	Full Complement	40	Sealed Type	12	M12 x 1.5	Eccentric
17	9	JNS_CFH16MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Cage	52	Shield Type	16	M16 x 1.5	Eccentric
18	10	JNS_CFH16UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Cage	52	Sealed Type	16	M16 x 1.5	Eccentric
19	11	JNS_CFH16RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Cage	52	Shield Type	16	M16 x 1.5	Eccentric
20	13	JNS_CFH16UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Cage	52	Sealed Type	16	M16 x 1.5	Eccentric
21	14	JNS_CFH16VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Full Complement	52	Shield Type	16	M16 x 1.5	Eccentric
22	15	JNS_CFH16VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	35	Cylinderical	18	Full Complement	52	Sealed Type	16	M16 x 1.5	Eccentric
23	16	JNS_CFH16VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Full Complement	52	Shield Type	16	M16 x 1.5	Eccentric
24	17	JNS_CFH16VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	35	Crowned	18	Full Complement	52	Sealed Type	16	M16 x 1.5	Eccentric
25	18	JNS_CFH18MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Cage	58	Shield Type	18	M18 x 1.5	Eccentric
26	19	JNS_CFH18UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Cage	58	Sealed Type	18	M18 x 1.5	Eccentric
27	20	JNS_CFH18RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Cage	58	Shield Type	18	M18 x 1.5	Eccentric
28	21	JNS_CFH18UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Cage	58	Sealed Type	18	M18 x 1.5	Eccentric
29	22	JNS_CFH18VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Full Complement	58	Shield Type	18	M18 x 1.5	Eccentric
30	24	JNS_CFH18VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	40	Cylinderical	20	Full Complement	58	Sealed Type	18	M18 x 1.5	Eccentric
31	25	JNS_CFH18VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Full Complement	58	Shield Type	18	M18 x 1.5	Eccentric
32	26	JNS_CFH18VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	40	Crowned	20	Full Complement	58	Sealed Type	18	M18 x 1.5	Eccentric
33	27	JNS_CFH20MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Cage	66	Shield Type	20	M20 x 1.5	Eccentric
34	28	JNS_CFH20UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Cage	66	Sealed Type	20	M20 x 1.5	Eccentric
35	29	JNS_CFH20RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Cage	66	Shield Type	20	M20 x 1.5	Eccentric
36	30	JNS_CFH20UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Cage	66	Sealed Type	20	M20 x 1.5	Eccentric
37	31	JNS_CFH20VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Full Complement	66	Shield Type	20	M20 x 1.5	Eccentric
38	32	JNS_CFH20VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	52	Cylinderical	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Eccentric
39	33	JNS_CFH20VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Full Complement	66	Shield Type	20	M20 x 1.5	Eccentric
40	35	JNS_CFH20VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	52	Crowned	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Eccentric
41	36	JNS_CFH20-1MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Cage	66	Shield Type	20	M20 x 1.5	Eccentric
42	37	JNS_CFH20-1UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Cage	66	Sealed Type	20	M20 x 1.5	Eccentric
43	38	JNS_CFH20-1RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Cage	66	Shield Type	20	M20 x 1.5	Eccentric
44	39	JNS_CFH20-1UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Cage	66	Sealed Type	20	M20 x 1.5	Eccentric
45	40	JNS_CFH20-1VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Full Complement	66	Shield Type	20	M20 x 1.5	Eccentric
46	41	JNS_CFH20-1VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	47	Cylinderical	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Eccentric
47	42	JNS_CFH20-1VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Full Complement	66	Shield Type	20	M20 x 1.5	Eccentric
48	43	JNS_CFH20-1VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	47	Crowned	24	Full Complement	66	Sealed Type	20	M20 x 1.5	Eccentric
49	44	JNS_CFH24MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Cage	80	Shield Type	24	M24 x 1.5	Eccentric
50	46	JNS_CFH24UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Cage	80	Sealed Type	24	M24 x 1.5	Eccentric
51	47	JNS_CFH24RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Cage	80	Shield Type	24	M24 x 1.5	Eccentric
52	48	JNS_CFH24UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Cage	80	Sealed Type	24	M24 x 1.5	Eccentric
53	49	JNS_CFH24VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Full Complement	80	Shield Type	24	M24 x 1.5	Eccentric
54	50	JNS_CFH24VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	62	Cylinderical	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Eccentric
55	51	JNS_CFH24VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Full Complement	80	Shield Type	24	M24 x 1.5	Eccentric
56	52	JNS_CFH24VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	62	Crowned	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Eccentric
57	53	JNS_CFH24-1MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Cage	80	Shield Type	24	M24 x 1.5	Eccentric
58	54	JNS_CFH24-1UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Cage	80	Sealed Type	24	M24 x 1.5	Eccentric
59	55	JNS_CFH24-1RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Cage	80	Shield Type	24	M24 x 1.5	Eccentric
60	57	JNS_CFH24-1UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Cage	80	Sealed Type	24	M24 x 1.5	Eccentric
61	58	JNS_CFH24-1VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Full Complement	80	Shield Type	24	M24 x 1.5	Eccentric
62	59	JNS_CFH24-1VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	72	Cylinderical	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Eccentric
63	60	JNS_CFH24-1VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Full Complement	80	Shield Type	24	M24 x 1.5	Eccentric
64	61	JNS_CFH24-1VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	72	Crowned	29	Full Complement	80	Sealed Type	24	M24 x 1.5	Eccentric
65	62	JNS_CFH30MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
66	63	JNS_CFH30UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
67	64	JNS_CFH30RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
68	65	JNS_CFH30UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
69	66	JNS_CFH30VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
70	68	JNS_CFH30VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	80	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric
71	69	JNS_CFH30VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
72	70	JNS_CFH30VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	80	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric
73	71	JNS_CFH30-1MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
74	72	JNS_CFH30-1UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
75	73	JNS_CFH30-1RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
76	74	JNS_CFH30-1UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
77	75	JNS_CFH30-1VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
78	76	JNS_CFH30-1VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	85	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric
79	77	JNS_CFH30-1VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
80	79	JNS_CFH30-1VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	85	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric
81	80	JNS_CFH30-2MAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
82	81	JNS_CFH30-2UUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
83	82	JNS_CFH30-2RMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Cage	100	Shield Type	30	M30 x 1.5	Eccentric
84	83	JNS_CFH30-2UURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Cage	100	Sealed Type	30	M30 x 1.5	Eccentric
85	84	JNS_CFH30-2VMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
86	85	JNS_CFH30-2VUUMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals	Hexagon socket on both sides	STAINLESS STEEL	90	Cylinderical	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric
87	86	JNS_CFH30-2VRMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Full Complement	100	Shield Type	30	M30 x 1.5	Eccentric
88	87	JNS_CFH30-2VUURMAB	[Stainless Eccentric] Cam Follower: hexagon socket on both sides - full complement - seals - crowned outer ring	Hexagon socket on both sides	STAINLESS STEEL	90	Crowned	35	Full Complement	100	Sealed Type	30	M30 x 1.5	Eccentric

Popis výrobku

UU: with seals - R: crowned outer ring - V: full complement
