M12 Female panel mount connector, Contacts: 4, unshielded, single wires, IP68, UL, M16x1.5

M12-T, series 813, Automation Technology - Voltage and Power Supply



Manufacturer	binder
Description	M12 Female panel mount connector, Contacts: 4, unshielded, single wires, IP68, UL, M16x1.5
Part Number	76 0240 0115 00044-0200
Mass	24.90
product segment	Automation Technology - Voltage and Power Supply
numbers of contacts	4
design	Female panel mount connector
locking system	screw
termination	single wires
installation type	Housing assembly
EMC	unshielded

coding	T-coded
degree of protection	IP68
wire gauge mm	1.38 mm²
wire gauge AWG	AWG 16
Mechanical durability	> 100 Mating cycles
Rated current	12.0 A
Rated voltage	63 V
pollution degree	3
overvoltage category	III
insulating material group	II

CAD-modellen

Offerteaanvraag

Productselectie

Index	Selector	Part Number	Description	Mass	product segment	numbers of contacts	design	locking system	termination	installation type	EMC	coding	degree of protection	wire gauge mm	wire gauge AWG	Mechanical durability	Rated current	Rated voltage	pollution degree	overvoltage category	insulating material group
1	1	76 0240 0115 00044-0200	M12 Female panel mount connector, Contacts: 4, unshielded, single wires, IP68, UL, M16x1.5	24.90	Automation Technology - Voltage and Power Supply	4	Female panel mount connector	screw	single wires	Housing assembly	unshielded	T-coded	IP68	1.38 mm²	AWG 16	> 100 Mating cycles	12.0 A	63 V	3	III	II

Productbeschrijving

M12 Female panel mount connector, Contacts: 4, unshielded, single wires, IP68, UL, M16x1.5

Documentatie

technical specification 76 0240 0115 00044-0200
