Mini vacuum cup holders for special bellows vacuum cups



Manufacturer	Vuototecnica
Description	Mini vacuum cup holders for special bellows vacuum cups
Art.	201850
Art.	20 18 50
Force (Kg)	0.63
C	9
D (Ø)	18

d (Ø)	12
E	21,5
F (Ø)	M12 x 1.25
L	109.5
Cup art.	01 18 50
Support included	00 08 07
Weight (g)	82.7

캐드 모델

가격 견적 요청(RFQ)

제품 선택

Index	Selector	Art.	Force (Kg)	C	D (Ø)	d (Ø)	E	F (Ø)	L	Cup art.	Support included	Weight (g)
1	1	20 18 50	0.63	9	18	12	21,5	M12 x 1.25	109.5	01 18 50	00 08 07	82.7
2	2	20 18 50L	0.63	9	18	12	21,5	M12 x 1.25	109.5	01 18 50	00 08 07	82.7
3	3	20 18 50T	0.63	9	18	12	21,5	M12 x 1.25	109.5	01 18 50	00 08 07	82.7

문서

공급업체에 문의하십시오.
