Mini vacuum cup holders for special bellows vacuum cups



Manufacturer	Vuototecnica
Description	Mini vacuum cup holders for special bellows vacuum cups
Art.	201823
Art.	20 18 23
Force (Kg)	0.63
C	7.5
D (Ø)	18

d (Ø)	6.5
E	23
F (Ø)	M12 x 1.25
L	111
Cup art.	01 18 23
Weight (g)	71.5

캐드 모델

가격 견적 요청(RFQ)

제품 선택

Index	Selector	Art.	Force (Kg)	C	D (Ø)	d (Ø)	E	F (Ø)	L	Cup art.	Weight (g)
1	1	20 18 23	0.63	7.5	18	6.5	23	M12 x 1.25	111	01 18 23	71.5
2	2	20 18 29	0.63	7.5	18	6.5	29	M12 x 1.25	117	01 18 29	71.8
3	3	20 18 35	0.63	7.5	18	6.5	35	M12 x 1.25	123	01 18 35	72.3
4	4	20 18 23L	0.63	7.5	18	6.5	23	M12 x 1.25	111	01 18 23	71.5
5	5	20 18 29L	0.63	7.5	18	6.5	29	M12 x 1.25	117	01 18 29	71.8
6	6	20 18 35L	0.63	7.5	18	6.5	35	M12 x 1.25	123	01 18 35	72.3
7	7	20 18 23T	0.63	7.5	18	6.5	23	M12 x 1.25	111	01 18 23	71.5
8	8	20 18 29T	0.63	7.5	18	6.5	29	M12 x 1.25	117	01 18 29	71.8
9	9	20 18 35T	0.63	7.5	18	6.5	35	M12 x 1.25	123	01 18 35	72.3

문서

공급업체에 문의하십시오.
