By ZWZ Bearing Group corp.

Spherical Roller Bearing 23800K Series, With Tapered Bore, Taper 1:12



Manufacturer	ZWZ Bearing Group corp.
Description	Spherical Roller Bearing 23800K Series, With Tapered Bore 23860CAK/W33
Part number	23860CAK/W33

CAD models

Request for quotation

Product selection

Level of detail

Index	Selector	Part No.	d	D	B	rsmin	Cr (kN)	Cor (kN)	Limiting Speed (grease) (rpm)	Limiting Speed (oil) (rpm)	d2	D1	b	k	da	Da	ra	e	y1	y2	y0	Weight (kg)
1	1	23860CAK/W33	300	380	60	3	640	1580	950	1400	328	357	60	6	310	368	2	.13	5.2	7.7	5	17.6
2	2	23864CAK/W33	320	400	60	2.1	670	1620	920	1280	346	376	60	6	332	388	2	.12	5.6	8.4	5.6	20.3
3	3	23884CAK	420	520	75	2.1	950	2630	750	950	454	490	75	5	430	504	2	.12	5.6	8.4	5.6	34.6
4	4	23884CAK/W33	420	520	75	2.1	950	2630	750	950	454	490	75	5	430	504	2	.12	5.6	8.4	5.6	34.6
5	5	238/500CAK/W33	500	620	90	3	1400	3800	420	520	542	586	90	8	512	606	2.5	.12	5.6	8.4	5.6	54
6	6	238/670CAK/W33	630	820	112	4	2200	6300	270	350	722	778	112	9	686	805	3	.11	6.1	9.1	6.3	128
7	7	238/750CAK/W33	750	920	128	5	2800	8100	240	310	806	873	128	12	770	902	4	.11	6.1	9.1	6.3	180
8	8	238/850CAK/W33	850	1030	136	5	3400	10000	180	250	910	980	136	12	866	1012	4	.11	6.1	9.1	6.3	236
9	9	238/1000CAKF1A/W20	1000	1220	165	6	4400	13600	150	300	1069	1154	165	9	972	1260	5	.114	5.916	8.808	5.784	402
10	10	238/1000CAKF3A/W20	1000	1220	165	6	4400	13600	150	300	1069	1154	165	9	972	1260	5	.114	5.916	8.808	5.784	402
11	11	238/1060CAK/W33	1060	1280	165	6	4500	14200	150	195	1134	1218	165	12	1082	1258	5	.11	6.1	9.1	6.3	425
12	12	238/1180CAKF1A/W20	1180	1420	180	6	5500	17600	150	190	1254	1349	180	9	1180	1450	5	.108	6.278	9.347	6.138	577
