Racks

Quantity	Manufacturer	Description	Part number
1	WINKEL	WINKEL Rack Modul 2 TYPE ZS 2 length: 1.998,05 mm, not hardened	228.502.000
1			Modul 2

CAD models

Request for quotation

Product selection

Index	Selector	Type	Article no.	a (mm)	b (mm)	c (mm)	No. of teeth	L (mm)	Weight (kg)
1	1	Modul 2	228.502.000	20	20	18	318	1998.05	5.5
2	2	Modul 3	228.503.000	30	30	27	216	2035.75	12.43
3	3	Modul 4	228.504.000	40	40	36	160	2010.62	22.5
4	4	Modul 5	228.505.000	50	50	45	128	2010.62	35
5	5	Modul 6	228.506.000	60	60	54	108	2035.75	50

Contact the supplier
