By Walter Stauffenberg GmbH & Co. KG

Spin-on filter, contamination indicator

Manufacturer	Walter Stauffenberg GmbH & Co. KG
Description	Spin-on filter, contamination indicator
Part number	GV-020B

CAD models

Request for quotation

Product selection

contamination indicator

Index	Selector	version	pressure range	coloured segments - green	coloured segments - yellow	coloured segments - red	actuating pressure for filter with by-pass valve	connection thread G	used as	adjustable range / actuating pressure	max over pressure	for filter type
1	1	GV-020B	0 ... -1.0 [bar]	0 ... -0.15 [bar]	-0.15 ... -0.20 [bar]	-0.20 ... -1.0 [bar]	0.20 [bar]	G 1/8	-	-	-	-
2	2	GV-035B	0 ... -1.0 [bar]	0 ... -0.25 [bar]	-0.25 ... -0.35 [bar]	-0.35 ... -1.0 [bar]	0.35 [bar]	G 1/8	-	-	-	-
3	3	GV-5	0 ... 30 [in Hg]	0 ... 4 [in Hg]	4 ... 6 [in Hg]	6 ... 30 [in Hg]	3 [PSI]	1/8" NPT	-	-	-	-
4	4	GV-10	0 ... 30 [in Hg]	0 ... 9 [in Hg]	9 ... 11 [in Hg]	11 ... 30 [in Hg]	5 [PSI]	1/8" NPT	-	-	-	-
5	5	SIS	0 ... 76 [in Hg]	0 ... 13 [in Hg]	13 ... 18 [in Hg]	18 ... 76 [in Hg]	5 [PSI]	G 1/8	-	-	-	-
