Size 3 - Pilot actuated valves

Pilot actuated valves, 5 ways, inteface to ISO 5599/1 size 3, monostable and bistable

Description	Valve to ISO 5599/1 Standard - size 3 - 5/2 monostable pilot actuated and return with mechanical spring
Type	UDSI3 KR/ZR
ISO Size	3
Weight (g)	1995

CAD models

Request for quotation

Product selection

Index	Selector	Type	Function	Pilot	Return	Response time energized at 6 bar (ms)	Response time de-energized at 6 bar (ms)	Flow rate 6 bar Δp=1 (Nl/min)	ISO Size	Weight (g)
1	1	UDSI3 KR/ZR	5/2 monostable	Pneumatic	Mechanical spring	38	42	3000	3	1995
2	2	UDSI3 KR/TQ	5/2 monostable	Pneumatic	Pneumatic spring	38	42	3000	3	1985
3	3	UDSI3 KR/KR	5/2 bistable	Pneumatic	Pneumatic	28	28	3000	3	1965
4	4	UDSI3 KR/TR	5/2 bistable	Big pneumatic	Small pneumatic	28	35	3000	3	1965
5	5	UDSI3 SR/SR	5/3 closed centre	Pneumatic	Mechanical spring	27	32	2900	3	2020
6	6	UDSI3 AR/AR	5/3 open centre	Pneumatic	Mechanical spring	27	32	3000	3	2020

Documentation
