Precision flow regulators

Unidirectional regolation - G1/8", G1/4", G1/2" ports

Description	Unidirectional flow regulator G1/8" - dn 0,9 mm
Type	URG8/1
Nominal diameter (mm)	0,9
Weight (g)	60

CAD models

Request for quotation

Product selection

Index	Selector	Type	Max flow rate 6 bar Δp=1 (Nl/min)	Nominal diameter (mm)	Port size	Weight (g)
1	1	URG8/1	28	0,9	G1/8"	60
2	2	URG8/2	200	2	G1/8"	60
3	3	URG8/5	550	5	G1/8"	60
4	4	URG4/10	900	10	G1/4"	120
5	5	URG2/25	2250	25	G1/2"	540

Documentation

Contact the supplier
