REF. RP400 TYPE I HEATED NOZZLE

Manufacturer	RABOURDIN
Description	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A10 DC=18 DE=4
Manufacturer Part Number	RP400IA-35-A100-18-4
RABOURDIN E-Shop link	https://eshop.rabourdin.fr/en/5040-buse-rp400-type-i.html
NOZZLE TYPE	I

DT mm	35
LC mm	A100
DC mm	18
DE mm	4
TIP	AMP

CAD models

Request for quotation

Product selection

Index	Selector	Manufacturer Part Number	Description	NOZZLE TYPE	DT mm	LC mm	DC mm	DE mm	TIP
1	1	RP400IA-25-A32-18-4	RP400 TYPE I TIP AMP HEATED MULTI-NOZZLE DT=25 LC=A32 DC=18 DE=4	I	25	A32	18	4	AMP
2	12	RP400IA-25-A50-18-4	RP400 TYPE I TIP AMP HEATED MULTI-NOZZLE DT=25 LC=A50 DC=18 DE=4	I	25	A50	18	4	AMP
3	23	RP400IA-25-A80-18-4	RP400 TYPE I TIP AMP HEATED MULTI-NOZZLE DT=25 LC=A80 DC=18 DE=4	I	25	A80	18	4	AMP
4	25	RP400IA-25-A100-18-4	RP400 TYPE I TIP AMP HEATED MULTI-NOZZLE DT=25 LC=A10 DC=18 DE=4	I	25	A10	18	4	AMP
5	26	RP400IA-25-A125-18-4	RP400 TYPE I TIP AMP HEATED MULTI-NOZZLE DT=25 LC=A12 DC=18 DE=4	I	25	A12	18	4	AMP
6	27	RP400IA-35-A32-18-4	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A32 DC=18 DE=4	I	35	A32	18	4	AMP
7	28	RP400IA-35-A50-18-4	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A50 DC=18 DE=4	I	35	A50	18	4	AMP
8	29	RP400IA-35-A80-18-4	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A80 DC=18 DE=4	I	35	A80	18	4	AMP
9	30	RP400IA-35-A100-18-4	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A10 DC=18 DE=4	I	35	A100	18	4	AMP
10	2	RP400IA-35-A125-18-4	RP400 TYPE I TIP AMP HEATED SINGLE-NOZZLE DT=35 LC=A12 DC=18 DE=4	I	35	A125	18	4	AMP
11	3	RP400IC-25-A32-18-4	RP400 TYPE I TIP CARBIDE HEATED MULTI-NOZZLE DT=25 LC=A32 DC=18 DE=4	I	25	A32	18	4	CARBURE
12	4	RP400IC-25-A50-18-4	RP400 TYPE I TIP CARBIDE HEATED MULTI-NOZZLE DT=25 LC=A50 DC=18 DE=4	I	25	A50	18	4	CARBURE
13	5	RP400IC-25-A80-18-4	RP400 TYPE I TIP CARBIDE HEATED MULTI-NOZZLE DT=25 LC=A80 DC=18 DE=4	I	25	A80	18	4	CARBURE
14	6	RP400IC-25-A100-18-4	RP400 TYPE I TIP CARBIDE HEATED MULTI-NOZZLE DT=25 LC=A100 DC=18 DE=4	I	25	A100	18	4	CARBURE
15	7	RP400IC-25-A125-18-4	RP400 TYPE I TIP CARBIDE HEATED MULTI-NOZZLE DT=25 LC=A125 DC=18 DE=4	I	25	A125	18	4	CARBURE
16	8	RP400IC-35-A32-18-4	RP400 TYPE I TIP CARBIDE HEATED SINGLE-NOZZLE DT=35 LC=A32 DC=18 DE=4	I	35	A32	18	4	CARBURE
17	9	RP400IC-35-A50-18-4	RP400 TYPE I TIP CARBIDE HEATED SINGLE-NOZZLE DT=35 LC=A50 DC=18 DE=4	I	35	A50	18	4	CARBURE
18	10	RP400IC-35-A80-18-4	RP400 TYPE I TIP CARBIDE HEATED SINGLE-NOZZLE DT=35 LC=A80 DC=18 DE=4	I	35	A80	18	4	CARBURE
19	11	RP400IC-35-A100-18-4	RP400 TYPE I TIP CARBIDE HEATED SINGLE-NOZZLE DT=35 LC=A100 DC=18 DE=4	I	35	A100	18	4	CARBURE
20	13	RP400IC-35-A125-18-4	RP400 TYPE I TIP CARBIDE HEATED SINGLE-NOZZLE DT=35 LC=A125 DC=18 DE=4	I	35	A125	18	4	CARBURE
21	14	RP400IZ-25-A32-18-4	RP400 TYPE I TIP Z HEATED MULTI-NOZZLE DT=25 LC=A32 DC=18 DE=4	I	25	A32	18	4	Z
22	15	RP400IZ-25-A50-18-4	RP400 TYPE I TIP Z HEATED MULTI-NOZZLE DT=25 LC=A50 DC=18 DE=4	I	25	A50	18	4	Z
23	16	RP400IZ-25-A80-18-4	RP400 TYPE I TIP Z HEATED MULTI-NOZZLE DT=25 LC=A80 DC=18 DE=4	I	25	A80	18	4	Z
24	17	RP400IZ-25-A100-18-4	RP400 TYPE I TIP Z HEATED MULTI-NOZZLE DT=25 LC=A100 DC=18 DE=4	I	25	A100	18	4	Z
25	18	RP400IZ-25-A125-18-4	RP400 TYPE I TIP Z HEATED MULTI-NOZZLE DT=25 LC=A125 DC=18 DE=4	I	25	A125	18	4	Z
26	19	RP400IZ-35-A32-18-4	RP400 TYPE I TIP Z HEATED SINGLE-NOZZLE DT=35 LC=A32 DC=18 DE=4	I	35	A32	18	4	Z
27	20	RP400IZ-35-A50-18-4	RP400 TYPE I TIP Z HEATED SINGLE-NOZZLE DT=35 LC=A50 DC=18 DE=4	I	35	A50	18	4	Z
28	21	RP400IZ-35-A80-18-4	RP400 TYPE I TIP Z HEATED SINGLE-NOZZLE DT=35 LC=A80 DC=18 DE=4	I	35	A80	18	4	Z
29	22	RP400IZ-35-A100-18-4	RP400 TYPE I TIP Z HEATED SINGLE-NOZZLE DT=35 LC=A100 DC=18 DE=4	I	35	A100	18	4	Z
30	24	RP400IZ-35-A125-18-4	RP400 TYPE I TIP Z HEATED SINGLE-NOZZLE DT=35 LC=A125 DC=18 DE=4	I	35	A125	18	4	Z

Documentation

CATALOG'S PAGE
