REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS)

Manufacturer	RABOURDIN
Description	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) H=60 L=160 mm
Manufacturer Part Number	5174-60-160
E-Shop link	https://eshop.rabourdin.fr/en/brass-wear-plate/279-equerre-de-frottement-laiton-avec-inserts.html
L1 mm	60
L mm	160

CAD models

Request for quotation

Product selection

Index	Selector	Manufacturer Part Number	Description	L1 mm	L mm
1	1	5174-40-160	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) L1=40 L=160 mm	40	160
2	2	5174-40-250	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) L1=40 L=250 mm	40	250
3	3	5174-45-160	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) H=45 L=160 mm	45	160
4	4	5174-45-250	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) H=45 L=250 mm	45	250
5	5	5174-60-160	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) H=60 L=160 mm	60	160
6	6	5174-60-250	REF. 5174 1/2 "VEE" AND 45° ANGLE WEAR SLIDE (BRONZE WITH INSERTS) H=60 L=250 mm	60	250

Documentation

CATALOG'S PAGE 1

CATALOG'S PAGE 2
