Product Type SPMHE & SPHHE NPT

Manufacturer	PEPPERS CABLE GLANDS LIMITED
Description	NPT Metallic Dome (Mushroom) Head Stopping Plug, 1/4"
Part number	SPMH1BE/NP/025NPT
IP RATING	IP66 & IP68 (100 metres for 7 days) & Type 4X/6P
OPERATING TEMP	-30°C to +100°C
MATERIAL	Brass
NPT Thread	1/4"

CAD models

Request for quotation

Product selection

Type

Index	Selector	NPT Thread	A/F	Overall Length	Weights (Kgs)
1	13	1/4"	6	20,6	0,027
2	14	3/8"	8	20,8	0,041
3	15	1/2"	10	25,4	0,062
4	16	3/4"	12	25,7	0,125
5	17	1"	12	30,5	0,202
6	18	1 1/4"	14	21,1	0,337
7	19	1 1/2"	17	21,5	0,451
8	20	2"	17	32,4	0,743
9	21	2 1/2"	19	45,4	1,499
10	22	3"	22	47	2,310
11	23	3 1/2"	22	48,3	3,133
12	24	4"	22	49,5	4,086

IP O-ring

Material

Locknut & IP Washer

Including Earth Tag

Including Serrated Washer

Quantity per kit

Nickel Plated

Product Description

“SPMH & SPHH” NPT Series Certified Metallic Stopping (Blanking) Plugs provide a method of sealing unused entries in Ex equipment. They maintain Ex eb method of protection and IP66, IP68 for IEC type applications. They are Class 1 Zone 1 approved for NEC and CEC type applications whilst also maintain Type 4X/6P rating.

Documentation

Datasheet
