Varistar - 19" Panel Mounts

Manufacturer	nVent SCHROFF
Description	Varistar 19" panel mount, 12U RAL7021 2PC
Part Number	23130018

CAD models

Request for quotation

Product selection

Index	Selector	Description	Height in U	Width in mm	Web link	Height in mm	Depth in mm
1	1	Varistar 19" panel mount, 12U RAL7021 2PC	12	49,5	web link	550	76
2	2	Varistar 19" panel mount, 16U AlZn 2PC	16	49,5	web link	750	76
3	3	Varistar 19" panel mount, 20U AlZn 2PC	20	49,5	web link	900	76
4	4	Varistar 19" panel mount, 24U AlZn 2PC	24	49,5	web link	1200	76
5	5	Varistar 19" panel mount, 29U AlZn 2PC	29	49,5	web link	1400	76
6	6	Varistar 19" panel mount, 33U AlZn 2PC	33	49,5	web link	1600	76
7	7	Varistar 19" panel mount, 38U AlZn 2PC	38	49,5	web link	1800	76
8	8	Varistar 19" panel mount, 42U AlZn 2PC	42	49,5	web link	2000	76
9	9	Varistar 19" panel mount, 47U AlZn 2PC	47	49,5	web link	2200	76
10	10	Varistar 19" panel mount, 8U AlZn 2PC	8	49,5	web link	400	76
11	11	19'' panel/slide mount Varistar 52U 2345x49,5x76mm Aluzinc	52	49,5	web link	2345	76
12	12	19'' panel/slide mount Varistar 52U 2345x49,5x76mm RAL7021	52	49,5	web link	2345	76
13	13	Varistar 19" panel mount, 16U RAL7021 2PC	16	49,5	web link	750	76
14	14	Varistar 19" panel mount, 20U RAL7021 2PC	20	49,5	web link	900	76
15	15	Varistar 19" panel mount, 24U RAL7021 2PC	24	49,5	web link	1200	76
16	16	Varistar 19" panel mount, 29U RAL7021 2PC	29	49,5	web link	1400	76
17	17	Varistar 19" panel mount, 33U RAL7021 2PC	33	49,5	web link	1600	76
18	18	Varistar 19" panel mount, 38U RAL7021 2PC	38	49,5	web link	1800	76
19	19	Varistar 19" panel mount, 42U RAL7021 2PC	42	49,5	web link	2000	76
20	20	Varistar 19" panel mount, 47U RAL7021 2PC	47	49,5	web link	2200	76
21	21	Varistar 19" panel mount, 8U RAL7021 2PC	8	49,5	web link	400	76
22	22	Varistar 19" panel mount, 12U RAL7035 2PC	12	49,5	web link	550	76
23	23	Varistar 19" panel mount, 16U RAL7035 2PC	16	49,5	web link	750	76
24	24	Varistar 19" panel mount, 20U RAL7035 2PC	20	49,5	web link	900	76
25	25	Varistar 19" panel mount, 24U RAL7035 2PC	24	49,5	web link	1200	76
26	26	Varistar 19" panel mount, 29U RAL7035 2PC	29	49,5	web link	1400	76
27	27	Varistar 19" panel mount, 33U RAL7035 2PC	33	49,5	web link	1600	76
28	28	Varistar 19" panel mount, 38U RAL7035 2PC	38	49,5	web link	1800	76
29	29	Varistar 19" panel mount, 42U RAL7035 2PC	42	49,5	web link	2000	76
30	30	Varistar 19" panel mount, 47U RAL7035 2PC	47	49,5	web link	2200	76
31	31	Varistar 19" panel mount, 8U RAL7035 2PC	8	49,5	web link	400	76
32	32	Varistar 19" panel mount, 12U AlZn 2PC	12	49,5	web link	550	76
