Pneumatic Auto Switch D-A67

Manufacturer	SMC
Description	Pneumatic Auto Switch, App. Load: IC Circuit;PLC, 30 mA Max. Current, Tie-Rod Mount
Manufacturer Part Number	D-A67
MI Item Number	02333375
Distributor	Motion
Motion Internal Description	D-A67 SENOR
E-Shop link	https://motion.com/products/sku/02333375
Product Page	https://motion.com/products/sku/02333375
Weight	0.21 lbs
Operating Temperature Range	-10 to +60 °C
Overall Length	45 mm

Standards Met	CE;IEC 529;IP67;JIS C 0920
Fluid Compatibility	Air
Overall Width	22 mm
Overall Height	16 mm
Mounting Type	Tie-Rod
Maximum Load Current	30 mA
Maximum Load Voltage	24 V dc
Applicable Load	IC Circuit;PLC
Electrical Connection	0.5m Lead Wire
Switch Action	Reed

CAD models

Buy now

Product selection

Index	Selector	MI Item Number	Motion Internal Description	Description	Weight	Operating Temperature Range	Overall Length	Standards Met	Fluid Compatibility	Overall Width	Overall Height	Mounting Type	Maximum Load Current	Maximum Load Voltage	Applicable Load	Electrical Connection	Switch Action
1	1	02333375	D-A67 SENOR	Pneumatic Auto Switch, App. Load: IC Circuit;PLC, 30 mA Max. Current, Tie-Rod Mount	0.21 lbs	-10 to +60 °C	45 mm	CE;IEC 529;IP67;JIS C 0920	Air	22 mm	16 mm	Tie-Rod	30 mA	24 V dc	IC Circuit;PLC	0.5m Lead Wire	Reed
