BergStik® Unshrouded Header, Through Hole, Double Row, 10 Positions, 2.54 mm Pitch, Vertical, 5.84 mm (0.23 in.) Mating, 3.05 mm (0.12 in.) Tail

BergStik® Unshrouded Headers Vertical double row

Manufacturer	FCI
Description	BergStik® Unshrouded Header, Through Hole, Double Row, 10 Positions, 2.54 mm Pitch, Vertical, 5.84 mm (0.23 in.) Mating, 3.05 mm (0.12 in.) Tail
Part Number	7731381810LF

CAD models

Request for quotation

Product selection

Index	Selector	Part Number	Description	Orientation	RoHS Lead Free Compatible	Number of rows	Length (Tail)	Plating (Contact area)	Length (Mating pin)	Number of contacts (per row)	Plating (Tail)	Attachment type (Board)
1	1	7731381810LF	BergStik® Unshrouded Header, Through Hole, Double Row, 10 Positions, 2.54 mm Pitch, Vertical, 5.84 mm (0.23 in.) Mating, 3.05 mm (0.12 in.) Tail	Vertical	Yes	2	3.05 mm (0.12 in.)	0.38 µm (15 µin.) Gold	5.84 mm (0.23 in.)	5	Tin	Through Hole

Contact the supplier

FCi

Manufacturer of Connector and Connector Systems
