D Sub Connector Housing, 78 Ways, High Density D Sub, AMPLIMITE 90 Series, Receptacle, Steel Body

Manufacturer	FARNELL
Description	D Sub Connector Housing, 78 Ways, High Density D Sub, AMPLIMITE 90 Series, Receptacle, Steel Body
Part Number	204508-1
Supplier Name	Farnell or Newark
Contact Termination	Crimp
Contact Termination Type	Crimp
For Use With	M 39029/57-354 or HDD-22 Socket Contacts
Gender	Receptacle

No. of Contacts	78Contacts
Brand Name	AMP - TE CONNECTIVITY
Connector Type	High Density D Sub
Product Range	AMPLIMITE 90 Series
Connector Body Material	Steel Body
D Sub Shell Size	DD
Connector Shell Size	DD
No. of Positions	78Ways

CAD models

Request for quotation

Product selection

Index	Selector	Part Number	Description	Contact Termination	Contact Termination Type	For Use With	Gender	No. of Contacts	Brand Name	Supplier Name	Connector Type	Product Range	Connector Body Material	D Sub Shell Size	Connector Shell Size	No. of Positions
1	1	204508-1	D Sub Connector Housing, 78 Ways, High Density D Sub, AMPLIMITE 90 Series, Receptacle, Steel Body	Crimp	Crimp	M 39029/57-354 or HDD-22 Socket Contacts	Receptacle	78Contacts	AMP - TE CONNECTIVITY	Farnell or Newark	High Density D Sub	AMPLIMITE 90 Series	Steel Body	DD	DD	78Ways
