Vertical Machined D-Sub Connectors, 627-M25-223-BN5

Manufacturer	EDAC Inc.
Description	The insulator is black. The shell is nickel plated. It is mounted via 4-40 UNC threaded board spacer with boardlocks.
Part Number	627-M25-223-BN5
Series	627M
Positions	25
Gender	Plug (PIN)

Contact Plating	Gold Flash Plating
Contact Code	.495" (12.57mm) P.C. Tail
Shell Plating	Nickel
Insulator Color	Black
Mounting & Grounding Options	#4-40 UNC Threaded Boardspacer with Boardlocks (P.C. Tail Only)

CAD models

Request for quotation

Product selection

Index	Selector	Part Number	Series	Positions	Gender	Contact Plating	Contact Code	Shell Plating	Insulator Color	Mounting & Grounding Options
1	1	627-M25-223-BN5	627M	25	Plug (PIN)	Gold Flash Plating	.495" (12.57mm) P.C. Tail	Nickel	Black	#4-40 UNC Threaded Boardspacer with Boardlocks (P.C. Tail Only)

Documentation

Datasheet
