NPV Series Pinch Valves

Manufacturer	Clippard USA
Description	3-Way Dual Tube Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 24 VDC
Part Number	NPV4-2D-06-24

CAD models

Request for quotation

Product selection

Index	Selector	Part Number	Description	Valve Type	Medium	Max Pressure	Power Consumption	Connector	Mounting	Response Time	Voltage
1	33	NPV4-2D-06-24	3-Way Dual Tube Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
2	34	NPV4-2D-06-12	3-Way Dual Tube Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
3	35	NPV4-1O-27-24	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	9 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
4	36	NPV4-1O-27-12	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	9 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
5	37	NPV4-1O-07-24	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
6	38	NPV4-1O-07-12	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
7	39	NPV4-1O-06-24	2-Way N.O. Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
8	40	NPV4-1O-06-12	2-Way N.O. Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
9	41	NPV4-1C-27-24	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	9 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
10	42	NPV4-1C-27-12	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	9 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
11	43	NPV4-1C-07-24	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
12	44	NPV4-1C-07-12	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID-3/8" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
13	45	NPV4-1C-06-24	2-Way N.C. Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
14	46	NPV4-1C-06-12	2-Way N.C. Pinch Valve, 1.5" Dia., 3/16" ID-5/16" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	7.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
15	47	NPV3-2D-25-24	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
16	48	NPV3-2D-25-12	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
17	1	NPV3-2D-05-24	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
18	2	NPV3-2D-05-12	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
19	3	NPV3-2D-04-24	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
20	4	NPV3-2D-04-12	3-Way Dual Tube Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
21	5	NPV3-1O-25-24	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
22	6	NPV3-1O-25-12	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
23	7	NPV3-1O-05-24	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
24	8	NPV3-1O-05-12	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
25	9	NPV3-1O-04-24	2-Way N.O. Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
26	10	NPV3-1O-04-12	2-Way N.O. Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
27	11	NPV3-1C-25-24	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
28	12	NPV3-1C-25-12	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	14 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
29	13	NPV3-1C-05-24	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
30	14	NPV3-1C-05-12	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID-1/4" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	20 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
31	15	NPV3-1C-04-24	2-Way N.C. Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
32	16	NPV3-1C-04-12	2-Way N.C. Pinch Valve, 1.250" Dia., 1/16" ID-3/16" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	4.2 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
33	17	NPV2-2D-23-24	3-Way Dual Tube Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
34	18	NPV2-2D-23-12	3-Way Dual Tube Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
35	19	NPV2-2D-03-24	3-Way Dual Tube Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
36	20	NPV2-2D-03-12	3-Way Dual Tube Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
37	21	NPV2-2D-02-24	3-Way Dual Tube Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
38	22	NPV2-2D-02-12	3-Way Dual Tube Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
39	23	NPV2-1O-23-24	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
40	24	NPV2-1O-23-12	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
41	25	NPV2-1O-03-24	2-Way N.O. Pinch Valve, 1" Dia, 1/16" ID-1/8" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
42	26	NPV2-1O-03-12	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
43	27	NPV2-1O-02-24	2-Way N.O. Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
44	28	NPV2-1O-02-12	2-Way N.O. Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
45	29	NPV2-1C-23-24	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
46	30	NPV2-1C-23-12	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	14 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
47	31	NPV2-1C-03-24	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
48	32	NPV2-1C-03-12	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID-1/8" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
49	49	NPV2-1C-02-24	2-Way N.C. Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	24 VDC
50	50	NPV2-1C-02-12	2-Way N.C. Pinch Valve, 1" Dia., 1/32" ID-3/32" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.5 Watts	18" Wire Leads	#4-40. M3 also available.	5 to 25 ms	12 VDC
51	51	NPV1-2D-01-24	3-Way Dual Tube Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 24 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	24 VDC
52	52	NPV1-2D-01-12	3-Way Dual Tube Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 12 VDC	3-Way Dual Tube	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	12 VDC
53	53	NPV1-1O-01-24	2-Way N.O. Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	24 VDC
54	54	NPV1-1O-01-12	2-Way N.O. Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	12 VDC
55	55	NPV1-1C-01-24	2-Way N.C. Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	24 VDC
56	56	NPV1-1C-01-12	2-Way N.C. Pinch Valve, 0.75" Dia., 0.030" ID-0.065" OD Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Fluids	30 psi	1.0 Watt	18" Wire Leads	#2-56. M2 also available.	5 to 25 ms	12 VDC
57	57	NPV2-1CP-03-12	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Medical Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	30 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
58	58	NPV2-1CP-03-24	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Medical Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	30 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
59	59	NPV2-1CP-23-12	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	14 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
60	60	NPV2-1CP-23-24	2-Way N.C. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	14 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
61	61	NPV3-1CP-05-12	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Medical Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	20 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
62	62	NPV3-1CP-05-24	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Medical Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	20 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
63	63	NPV3-1CP-25-12	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	14 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
64	64	NPV3-1CP-25-24	2-Way N.C. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	14 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
65	65	NPV4-1CP-07-12	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Medical Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	20 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
66	66	NPV4-1CP-07-24	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Medical Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	20 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
67	67	NPV4-1CP-27-12	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	9 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
68	68	NPV4-1CP-27-24	2-Way N.C. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Closed	Air, Water, Gas & Compatible Fluids	9 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
69	69	NPV2-1OP-03-12	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Medical Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	30 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
70	70	NPV2-1OP-03-24	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Medical Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	30 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
71	71	NPV2-1OP-23-12	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	14 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
72	72	NPV2-1OP-23-24	2-Way N.O. Pinch Valve, 1" Dia., 1/16" ID x 1/8" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	14 psi	1.5 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
73	73	NPV3-1OP-05-12	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Medical Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	20 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
74	74	NPV3-1OP-05-24	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Medical Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	20 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
75	75	NPV3-1OP-25-12	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	14 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
76	76	NPV3-1OP-25-24	2-Way N.O. Pinch Valve, 1.250" Dia., 1/8" ID x 1/4" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	14 psi	4.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
77	77	NPV4-1OP-07-12	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Medical Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	20 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
78	78	NPV4-1OP-07-24	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Medical Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	20 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC
79	79	NPV4-1OP-27-12	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Food Grade Tubing, 12 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	9 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	12 VDC
80	80	NPV4-1OP-27-24	2-Way N.O. Pinch Valve, 1.5" Dia., 1/4" ID x 3/8" OD / Food Grade Tubing, 24 VDC	2-Way Normally-Open	Air, Water, Gas & Compatible Fluids	9 psi	7.2 Watts	18" Wire Leads	Panel	5 to 25 ms	24 VDC

Additional Circuitry Option

Documentation

Catalogue Page
